The assembly of neodymium pot magnets with a swivel hook is also called a magnetic swivel hook. It's composed of a high-quality A3 steel cup and neodymium ring magnet.
The design of the swivel hook makes it used as a magnetic ceiling hook and magnetic wall hook. Their reversible hook on the top of the magnet assembly allows it to hang all kinds of objects on vertical metal surfaces. Each magnetic swivel hook contains a ring-shaped neodymium magnet, making them a various option for hanging jackets, keys, or even small bags in a filing cabinet, refrigerator, or other steel surfaces. Compared with plastic magnetic hooks, these steel reversible magnetic hooks used for heavy-duty hanging
Model | D | A | B | C | H | L | W | Vertical Force (Kgs) | Side Force (Kgs) | Weight(g) |
RMH-D25 | 25 | 20 | 13.5 | 24 | 15.5 | 55 | 23 | 14 | 3.5 | 38 |
RMH-D32 | 32 | 20 | 13.5 | 24 | 15.5 | 55 | 23 | 23 | 5.5 | 52 |
RMH-D36 | 36 | 20 | 13.5 | 24 | 15.5 | 55 | 23 | 40 | 6.5 | 65 |
RMH-D40 | 40 | 20 | 13.5 | 24 | 15.5 | 55 | 23 | 50 | 7 | 84 |
RMH-D42 | 42 | 20 | 13.5 | 24 | 16.5 | 55 | 23 | 65 | 8 | 92 |
Remind: Although the surface of the neodymium pot (cup) magnet with swivel hook has been anti-rust treated with electroplating, if it is not used and stored properly, it will still rust. Please put the neodymium magnetic swivel hooks in dry and room temperature environment, preferably in a sealed bag.
As a professional neodymium magnet manufacturer in China, we supply neodymium magnets with different types of swivel magnets, so you can surely get the type you want from us. Contact us now for swivel magnetic hooks.
Version for punching machine
Version for turning machine
