Neodymium Flat Shallow Pot Magnets


A flat shallow pot (cup) magnet is a flat steel-covered disc magnet without any mounting hole, bushing, stud, and stem. To meet different requirements of magnetic force and working temperature, various magnetic materials can be used to make flat shallow pot magnets, the strongest and most widely used type is neodymium flat shallow pot magnets.


Neodymium (NdFeB) flat shallow pot magnet is a mono-pole neodymium magnet with strong magnetic force in a small volume. In addition to the inner magnet and outer iron shell structure, the magnetic clamping force of the neodymium flat pot/cup magnet is also decided by the material, thickness, and flatness of the adsorption surface. Thanks to the strong magnetic force, neodymium strong round base magnets are widely used holding&clamping magnets. You can use a flat shallow pot/cup magnet of neodymium for clamping of the ceiling, sign, and banner, you can also use this neodymium round base magnet as a magnetic holder in the factory, workshop, warehouse. It's easy to use and removes flat shallow pot magnets.


Summary Of Flat Neodymium Shallow Pot Magnets:


Component Material: neodymium disc magnets + A3 flat steel pot + ABS plastic ring or epoxy glue

Available Surface Treatment: Nickel, Zinc, spray colorful plastic

Standard Size:  diameter-- 10mm, 20mm, 25mm, 32mm,36mm,42mm,48mm,60mm,75mm,80mm.90mm,120mm

Magnetic Grade: N35, N38, N40, N42, N45,N48,N50,N52

Working Temp.: -40 to 80℃(for standard ones), the flat pot magnets for higher working temperature can be customized


Parameters Of Standard Flat Shallow Pot/cup Magnets Of Ndfeb(neodymium):


Strong Neodymium Round Base Magnet


Item Code

D(mm)

H(mm)

Weight(g)

Pull Force(kg)

NdFeB-U-10

10

5

4

2

NdFeB-U-12

12

5

5

4

NdFeB-U-16

16

5

8

8

NdFeB-U-20

20

7

16

12

NdFeB-U-25

25

8

25

25

NdFeB-U-32

32

8

40

34

NdFeB-U-36

36

8

51

50

NdFeB-U-42

42

8.6

78

72

NdFeB-U-48

48

11

121

81

NdFeB-U-55

55

12

209

95

NdFeB-U-60

60

15

256

160

NdFeB-U-70

70

17

467

200

NdFeB-U-75

75

18

510

270

NdFeB-U-80

80

18

681

300

NdFeB-U-90

90

18

841

360

NdFeB-U-120

120

18

1420

480




Two Edge Versions for Neodymium Strong Round Flat Shallow Pot Magnets


Strong Neodymium Round Base Magnet

Version for punching machine

Strong Neodymium Round Base Magnet

Version for turning machine
