Neodymium Pot Magnet With Hook


Neodymium cup/pot magnets with steel hook are shorted as neodymium hook magnets, they are composed of NdFeB disc magnets and high-quality A3 steel cups with detachable steel hooks for hanging and holding. You can wear rubber boots on the magnetic base to protect the magnets and the contact surface where the magnets are attached.


Common neodymium cup magnets with hooks are made with N35 neodymium magnets, which provide amazing magnetic force for their small size. Neodymium hook magnets are used for ceiling hanging and wall holding Our neodymium hook magnets are plated with a triple layer of Ni-Cu-Ni (Nickel + Copper + Nickel) to supply maximum protection against corrosion & rust. We also have to spray plastic surface treatment for neodymium pot magnets with hooks.



Summary Of Neodymium Pot Magnet With Hook:


Component Material: neodymium disc magnets + A3 steel cup with internally threaded stem + ABS plastic ring or epoxy glue+steel open hook

Available Surface Treatment: Nickel, Zinc, spray colorful plastic

Standard Size:  diameter-- 10mm, 16mm, 20mm, 25mm, 32mm,36mm,42mm,48mm,60mm,75mm

Magnetic Grade: N35, N38, N40, N42, N45,N48,N50,N52

Working Temp.: -40 to 80℃(for standard ones), the pot magnets with a hook for higher working temperature can be customized


Parameters Of Common Neodymium Pot Magnets With Hooks:


Neodymium Pot Magnet With Hook


Item Code

D(mm)

d(mm)

M(mm)

h(mm)

H(mm)

Pull Force(kg)

Weight(g)

NdFeB-E10

10

6

4

5

11

1.3

7

NdFeB-E12

12

6

4

5

13

2.8

8

NdFeB-E16

16

6

4

5

13

5.5

13

NdFeB-E20

20

8

4

7

15

9

20

NdFeB-E25

25

10

5

8

17

22

32

NdFeB-E32

32

10

6

8

18

34

51

NdFeB-E36

36

10

6

8

18

41

62

NdFeB-E42

42

12

8

9

20

68

91

NdFeB-E48

48

12

8

11.5

24

81

146

NdFeB-E60

60

14

8

15

30

113

315

NdFeB-E75

75

16

10

18

34

164

570


Remind: Although the surface of the neodymium pot (cup )magnet with a hook has been anti-rust treated with electroplating, if it is not used and stored properly, it will still rust. Please put the neodymium magnetic hooks in dry and room temperature environment, preferably in a sealed bag.


Feature Summary Of Neodymium Hook Magnets:


1. The neodymium hook magnet has a small volume and powerful magnetic strength.

2. The magnetic lines are concentrated on one side to obtain the maximum holding strength and plated with three layers of Ni Cu Ni.

3. According to the change of size and force, various sizes of M4, M5, M6, and M8 thread hooks can be matched.

4. The neodymium hook magnet is magnetized axially through thickness.

5. The magnet must be fully attached on a horizontal surface to maximize magnetic pull force, for example, used as a magnetic ceiling hook.


Application Of Neodymium Pot Magnet With Hook:


1. Strong neodymium pot magnets with steel hooks are the best solution for all types of applications that strong holding strength and durable hooks are needed.

2. Neodymium cup magnets with durable steel hooks are useful for hanging heavy objects, tools, lights, equipment, signs & banners, for organizing cables, wires, and other items in warehouses, office spaces, workstations, and so on.

3. Neodymium magnetic hooks can be used in homes, schools, warehouses, garages, offices, and even cruise ships, whether they have magnetic or metal surfaces


Order Neodymium Hook Magnets From Meank For A Better Deal!


We can produce neodymium hook magnets according to the customer's specifications. We have made a lot of customized neodymium hook magnets for worldwide customers. We have neodymium pot/cup magnets with all types of hooks, which include closed hook, swivel hook, carabiner hook, reversible hook, rotary hook, and eyelet hook. Contact us now for neodymium hook magnets.




Two Edge Versions for the Steel Cup of Neodymium Hook Magnets


Neodymium Hook Magnets

Version for punching machine

Neodymium Hook Magnets

Version for turning machine
